600kW Gas/HVO/Oil Fired Packaged Boiler Plant

• Maximum Output: 600kW Gas or Oil
• Boiler: Viessmann
• Burner: Oil
• Oil: Riello RL50
• Gas: RS50
• Pumps: tpd 60-240/2 (twin bed) fixed speed
• Temperature Range: 60-90°C
• LTHW Connections: DN100
• Electrical: 32 amp 3 phase
• Gas Connection: 50mm
• Water Connection: 15mm
• Flow Rate: 11.90kg/s and 70kPA
• Dimensions (LxWxH): 3030mm x 2428mm x 2599mm
• Weight: 3.5 tonnes (approx)
• Pressurisation Plant: Included
• Telemetry: Trend IQ3 controller with GSM modem reporting
• Variable Temperature: Yes
• Noise: 72 dBA
• Handling Options: HIAB
• HWS Connection: DN40
• HWS Flow Rate: 1 Kg/s
• Max HWS Temperature: 60°C
• Maximum Static: 3Bar – max system volume 1500 litres (500 litre expansion vessel included)
• CWS Connection: DN40

Towards the highest end of our containerised boiler range, is the 600kW system. With twin head circulation pumps and a choice of oil or natural gas fired fuels, the plant room is a versatile system that can provide consistent hot water and heat for a variety of different applications.

The 600kW contains a sophisticated monitoring system that tracks the performance of the boiler. The Trend 963 Supervisor alerts our Maidstone control centre as soon as any problems arise, informing us what has caused the issue, so we can address it effectively and quickly. Not only can we assess the problems remotely, but we can also tweak some of the settings without leaving our base in Kent. This can save you time and money in the upkeep of your system.

Ideal Heat Solutions continually seeks the most effective boiler technology for our clients. Packaged plants such as this 600kW system ensure that we can provide versatile boilers quickly, delivering and setting them up with a quick turnaround. We can conduct a comprehensive, FREE site survey to analyse the specific requirements of your site before we recommend any of our systems. Call our team today or alternatively complete the online enquiry form below for an immediate response.

• Universities
• Colleges
• Schools
• Refiniries
• Factories
• Construction
• Care Homes
• Hospitals
• District Heating Systems
• Contingency Plans
